Tækniupplýsingar:
160 amp MIG suða fyrir 5kg rúllur
Auðvelt að umpóla fyrir gaslausa suðu
3m MIG suðukapall og byssa
16mm² jarðkapall
Frá 0.8mm fyrir stál og ryðfrítt stál (MAG)
Frá 2mm fyrir ál (MIG)
Stærð: 525 x 260 x 340 mm
230V/50Hz – 160A
Nettóþyngd: 14.5 kg
.
Einföld pinnasuðuvél fyrir léttari samsetningar (stigar, pallar)All devices are built in modern inverter technology
Ideally suited for assembly work (on the ladder, on the scaffolding, ...) and, with protection class IP 21 S, generally also for outdoor work
Accurate setting of welding parameters via digital display
Universally applicable for welding of all common electrode types
Suitable for use on the generator eg in company workshops, schools, metal construction, on construction sites or for farmers
TIG pulses enable welding with reduced heat input
HF high-frequency ignition ignites during TIG welding without touching the workpiece
The quietly running fan dissipates the heat well out of the devices, thus achieving a long duty cycle
Three-year Schweißkraft guarantee
450 amp MIG/MAG suðuvél þriggja fasa
Fyrir efni frá 0,8 mm fyrir stál og ryðfrítt (MAG)
Fyrir efni frá 2,0mm fyrir ál (MIG)
Gerð fyrir víra 0,8, 1,0, 1,2 og 1,6mm
Vatnskældur barki SMB 400/4 m
Jarðkapall 4m / 70 mm²
Þrýstiminnkari
Rúlluhaldari.
Feed roller 0.8/1.2 mm
Torch SMB 15, 3m
Ground cable 3m, 16 mm²
Pressure reducer small
Cooling
Torch cooling: gas
Dimensions and weights
Length approx.: 525 mm
Width/depth approx.: 260 mm
Height approx.: 340 mm
Weight approx.: 14.5 kg
Duty cycle
Duty cycle at Imax. 40°C: 20 %
Current at 100% DC 40°C: 80 A
Electrical Data
Supply voltage: 1 x 230 V
Mains frequency: 50 Hz
Setting range
MIG/MAG: 25 160 A
Wire feed
weldable wires steel0.6 mm
weldable wires stainless steel0.8 mm
weldable wires flux core wire0.9 mm
Wire feet unit: 2 Rollers
Speed: 1.0 14 m/min
Wire feed rolls/driven: 1 Roll
VPE: 1
